FT 180/A 4V R EYE

FT 180/A 4V R EYE

4 Way hydraulic hose reels with radial attachment

Uses
boom trucks
Suitable for crane
Suitable for aerial platforms
Suitable for excavator
Suitable for offroad
Description

4 Way hydraulic hose reels with radial attachment. For hoses with eye-fitting and "bondes seals" washers.

Technical table
Models A B Max reel lenght (mm) and connections - 1/4" Max reel lenght (mm) and connections - 3/8" Weight C L
Um Ø mm mm Ø 1/4" Ø 3/8" kg Ø mm Ø mm
FT 180/A200 4V R EYE 200 86 1500 - 8,5 27(1/4") 36(3/8") 189(1/4") 220(3/8")
FT 180/A270 4V R EYE 270 86 2500 1800 12,6 27(1/4") 36(3/8") 189(1/4") 220(3/8")
FT 180/A300 4V R EYE 300 86 4000 2700 14,5 27(1/4") 36(3/8") 189(1/4") 220(3/8")
FT 180/A325 4V R EYE 325 86 5000 3500 15 27(1/4") 36(3/8") 189(1/4") 220(3/8")
FT 180/A385 4V R EYE 385 86 7000 5500 16,5 27(1/4") 36(3/8") 189(1/4") 220(3/8")
FT 180/A235 4V R EYE 235 86 2000 - 6 27(1/4") 36(3/8") 189(1/4") 220(3/8")
FT 180/A340 4V R EYE 340 86 5200 4000 18 27(1/4") 36(3/8") 189(1/4") 220(3/8")

* price of the product vat excluded

Documentation PDF
Catalog FT 180/A 4V EYE
